16. POSITIONING MODE
No./
symbol/name
Setting
digit
Function
Initial
value
[unit]
Control
mode
CP
CL
PS
PT04
*ZTY
Home
position
return type
_ _ _ x
Home position return method
0: Dog type (rear end detection, Z-phase reference)/torque limit changing dog type
1: Count type (front end detection, Z-phase reference) (Note 1)
2: Data set type/torque limit changing data set type
3: Stopper type (Note 1)
4: Home position ignorance (servo-on position as home position) (Note 1)
5: Dog type (rear end detection, rear end reference) (Note 1)
6: Count type (front end detection, front end reference) (Note 1)
7: Dog cradle type (Note 1)
8: Dog type (front end detection, Z-phase reference) (Note 1, 2)
9: Dog type (front end detection, front end reference) (Note 1)
A: Dogless type (Z-phase reference) (Note 1, 2)
0h
Note 1.
Setting "1" and "3" to "A" will trigger [AL. 37 Parameter error] for the
indexer method.
_ _ x _
Home position return direction
0: Address increasing direction
1: Address decreasing direction d
Setting "2" or more to this digit will be recognized as "1: Address decreasing
direction".
1h
_ x _ _
Home position shift distance multiplication
Set a multiplication of [Pr. PT07 Home position shift distance].
0: × 1
1: × 10
2: × 100
3: × 1000
"0" to "3" can be used for the indexer method.
When [degree] of "Position data unit" is set in [Pr. PT01] in the point table method or
program method, only "0" and "1" are enabled. ("2" or more will be recognized as
"1".)
0h
x _ _ _
For manufacturer setting
0h
PT05
ZRF
Home
position
return speed
Set a (linear) servo motor speed at home position return.
Setting range: 0 to permissible instantaneous speed
100
[r/min]
PT06
CRF
Creep speed
Set a creep speed after proximity dog at home position return.
Setting range: 0 to permissible instantaneous speed
10
[r/min]
