17 - 23
17．Positioning mode (pushing operation)
Point
table
No.
Position data /
Pushing limit
position
[10^stm μm]
Servo motor rotation
speed / speed limit
value
[r/min]
Acceleration
time
constant
[ms]
Deceleration
time
constant
[ms]
Dwell
[ms]
Auxiliary
function
M code
Pushing
torque
[0.1%]
1
8.00
3000
100
150
0
1
0(Note1)
0(Note1)
2
4.00
500
0(Note1)
0(Note1)
0(Note1)
18
0(Note1)
500
3
0
2000
100
300
0
0
15
0(Note1)
Note1： The set value of the point table becomes invalid. Refer to section 6.1.3 of this specification
for details.
(2) Timing chart
torque
PERR
(pushing error)
TLC
(During pushing)
ST1 (start)
RES (reset)
pushing start position
pushing limit position
current position
command position
detection
Turn on TLC for 100msec continuous detection (it can be changed with Pr PS03)
