17．Positioning mode (pushing operation)
No./symbol/
name
Setting
digit
Function
Initial
value
[unit]
Control
mode
C
P
CL
P
S
PD24
*DO2
Output device
selection 2
_ _ x x
Device selection
Any output device can be assigned to the CN1-23 pin.
Refer to [Pr. PD23] for settings.
0Ch
_ x _ _
For manufacturer setting
0h
x _ _ _
0h
PD25
*DO3
Output device
selection 3
_ _ x x
Device selection
Any output device can be assigned to the CN1-24 pin.
Refer to [Pr. PD23] for settings.
04h
_ x _ _
For manufacturer setting
0h
x _ _ _
0h
PD26
*DO4
Output device
selection 4
_ _ x x
Device selection
Any output device can be assigned to the CN1-25 pin.
Refer to [Pr. PD23] for settings.
07h
_ x _ _
For manufacturer setting
0h
x _ _ _
0h
PD28
*DO6
Output device
selection 6
_ _ x x
Device selection
Any output device can be assigned to the CN1-49 pin.
Refer to [Pr. PD23] for settings.
02h
_ x _ _
For manufacturer setting
0h
x _ _ _
0h
