(3) Pause the servo motor
Click "Pause" (d) to temporarily stop the servo motor.
While the servo motor is temporarily stopped, click "Operation Start" (c) to restart the rotation by the
amount of the remaining travel distance.
While the servo motor is temporarily stopped, click "Stop" (e) to clear the remaining travel distance.
During pushing operation, clicking "Pause" (d) is invalid and the servo motor does not stop.
To stop the motor during the pushing operation, click "Forced stop" (f).
(4) Stop the servo motor
Click "Stop" (e) to stop the servo motor. At this time, the remaining travel distance is cleared. Click
"Operation Start" (c) to restart the rotation.
During pushing operation, clicking "Stop" (e) is invalid and the servo motor does not stop.
To stop the motor during the pushing operation, click "Forced stop" (f).
(5) Forced stop of the servo motor software
Click "Forced Stop" (f) to make an instantaneous stop. When "Forced Stop" is enabled, the servo
motor does not drive even if "Operation Start" is clicked. Click "Forced Stop" again to enable
"Operation Start" to be clicked.
(6) Switch to the normal operation mode
Before switching from the test operation mode to the normal operation mode, turn off the driver.
