Functional Safety
GIC block Safety Mechanism ID Description
4 GICD→ITS AXI4-Stream interface error
5 GICD→SPI Collator AXI4-Stream interface error
6 GICD ACE-Lite manager interface error
7 SPI RAM DED error
8 SGI RAM DED error
9 Reserved
10 LPI RAM DED error
11 GICD→remote GICD AXI4-Stream interface error
12 GICD Q-Channel interface error
13 GICD P-Channel interface error
14 SPI RAM address decode error
15 SGI RAM address decode error
16 Reserved
17 LPI RAM address decode error
18 FMU dual lock-step error
GICD
19 FMU ping ACK error
20 FMU APB parity error
21 GICD→Wake Request AXI4-Stream interface error
22 GICD PageOffset or chip ID error
23 MBIST REQ error.
This Safety Mechanism is disabled by default.
24 SPI RAM SEC error
25 SGI RAM SEC error
26 Reserved
27 LPI RAM SEC error
28 User custom SM0 error
GICD
29 User custom SM1 error
30 GICD→ITS monolithic switch error
31 GICD→ITS Q-Channel interface error
32 GICD→ITS monolithic interface error
GICD
33 GICD FMU ClkGate override.
This Safety Mechanism is disabled by default.
0 Reserved
1 PPI dual lock-step error
2 PPI→GICD AXI4-Stream interface error
3 PPI→CPU interface AXI4-Stream interface error
4 PPI Q-Channel interface error
5 PPI RAM DED error
6 PPI RAM address decode error
7 PPI RAM SEC error
PPI
8 PPI User0 SM
