Arm
®
CoreLink™ GIC-600AE Generic Interrupt Controller
Technical Reference Manual
Document ID: 101206_0003_04_en
Issue: 04
Operation
MAPVI commands
Error mnemonic Encoding IERR Stall Mask Description
MAPVI_PHYSICALID_OOR 0x10A06 0 1 CEE A MAPVI is received that has a physical ID outside the range supported.
The supported range is >16-<8096 bits.
MOVI commands
Error mnemonic Encoding IERR Stall Mask Description
MOVI_DEVICE_OOR 0x10101 0 1 CEE A MOVI has tried to map a device that is outside the range that the
ITS supports.
See GITS_BASER0, and for information about the supported range,
see GITS_TYPER.
MOVI_COLLECTION_OOR 0x10103 0 1 CEE A MOVI has tried to use a collection that is outside the range that the
ITS supports.
See GITS_BASER1, and for information about the supported range,
see GITS_TYPER.
MOVI_UNMAPPED_DEVICE 0x10104 0 1 CEE A MOVI has tried to move an interrupt from a device that is not
mapped
MOVI_ID_OOR 0x10105 0 1 CEE A MOVI has tried to use an EventID that is outside the size that the
corresponding MAPD command supports
MOVI_UNMAPPED_INTERRUPT 0x10107 0 1 CEE A MOVI command has tried to operate on an interrupt that is not
mapped
MOVI_UNMAPPED_COLLECTION 0x10109 0 1 CEE A MOVI command has tried to operate on a collection that is not
mapped
MOVALL commands
Error mnemonic Encoding IERR Stall Mask Description
MOVALL_TGT_OOR 0x10E20 1 0 - MOVALL from a core that does not exist.
Command is ignored.
MOVALL_DST_TGT_OOR 0x10E21 1 0 - MOVALL to a core that does not exist.
Command is ignored.
MOVALL_CHIP_OFFLINE_OOR 0x10E22 1 0 - MOVALL to a chip that is out-of-range, or from a chip that is offline.
Command is ignored.
MOVALL_ENABLE_LPI_OFF 0x10E23 1 0 - MOVALL from a core where GICR_CTLR.Enable_LPIs is 0.
Command is ignored.
MOVALL_DST_ENABLE_LPI_OFF 0x10E24 1 0 - MOVALL to a core where GICR_CTLR.Enable_LPIs is 0, or to a
destination chip that is offline.
LPIs on MOVALL source are dropped.
DISCARD commands
Error mnemonic Encoding IERR Stall Mask Description
DISCARD_DEVICE_OOR 0x10F01 0 1 CEE A DISCARD has tried to use a device that is outside the range that
the ITS supports.
See GITS_BASER0, and for information about the supported range,
see GITS_TYPER.
DISCARD_UNMAPPED_DEVICE 0x10F04 0 1 CEE A DISCARD has tried to drop an interrupt from a device that is not
mapped
DISCARD_ID_OOR 0x10F05 0 1 CEE A DISCARD command has tried to use an EventID that is outside
the size that the corresponding MAPD command supports
Copyright © 2018–2020, 2022 Arm Limited (or its affiliates). All rights reserved.
Non-Confidential
Page 83 of 268
