Operation
DISCARD commands
Error mnemonic Encoding IERR Stall Mask Description
DISCARD_UNMAPPED_INTERRUPT 0x10F07 0 1 CEE A MOVI command has tried to operate on an interrupt that is not
mapped
DISCARD_ITE_INVALID 0x10F10 0 1 CEE A MOVI command has tried to operate on an EventID that is not
supported by the corresponding MAPD command
CLEAR commands
Error mnemonic Encoding IERR Stall Mask Description
CLEAR_DEVICE_OOR 0x10501 0 1 CEE A CLEAR has attempted to use a device that is outside the range that
the ITS supports.
See GITS_BASER0, and for information about the supported range, see
GITS_TYPER.
CLEAR_UNMAPPED_DEVICE 0x10504 0 1 CEE A CLEAR has tried to drop an interrupt from a device that is not
mapped
CLEAR_ID_OOR 0x10505 0 1 CEE A CLEAR has tried to drop an interrupt from an EventID that is not
supported by the corresponding MAPD command
CLEAR_UNMAPPED_INTERRUPT 0x10507 0 1 CEE A CLEAR has attempted to drop an interrupt that is not mapped
CLEAR_ITE_INVALID 0x10510 0 1 CEE A CLEAR has tried to drop an interrupt from an EventID that is not
supported by the corresponding MAPD command
CLEAR_TGT_OOR 0x10520 1 0 - A CLEAR has been sent to an illegal target
CLEAR_CHIP_OFFLINE_OOR 0x10522 1 0 - A CLEAR has been sent to a target on a chip that is offline
CLEAR_LPI_OFF 0x10523 1 0 - A CLEAR has been sent to a target that does not have LPIs enabled
CLEAR_PHYSICALID_OOR 0x10526 1 0 - A CLEAR has tried to drop an interrupt, which has a physical ID that is
not supported by the target
INV commands
Error mnemonic Encoding IERR Stall Mask Description
INV_DEVICE_OOR 0x10C01 0 1 CEE An INV has tried to use a device that is outside the range that the ITS
supports.
See GITS_BASER0, and for information about the supported range, see
GITS_TYPER.
INV_UNMAPPED_DEVICE 0x10C04 0 1 CEE An INV has tried to invalidate an interrupt from a device that is not
mapped
INV_ID_OOR 0x10C05 0 1 CEE An INV has tried to use an EventID that is outside the size that the
corresponding MAPD command supports
INV_UNMAPPED_INTERRUPT 0x10C07 0 1 CEE An INV has tried to invalidate an interrupt that is not mapped
INV_ITE_INVALID 0x10C10 0 1 CEE An INV has tried to invalidate an interrupt with an EventID that is invalid
INV_TGT_OOR 0x10C20 1 0 - An INV has tried to invalidate an interrupt that is mapped to an invalid
target
INV_CHIP_OFFLINE_OOR 0x10C22 1 0 - An INV has tried to invalidate an interrupt that is mapped to a chip that is
offline
INV_LPI_OFF 0x10C23 1 0 - An INV has tried to invalidate an interrupt that is mapped to a target that
does not have LPIs enabled.
See GICR_CTLR.Enable_LPIs.
INV_PHYSICALID_OOR 0x10C26 1 0 - An INV has tried to invalidate an interrupt with a physical ID that is larger
than the target supports.
See GICR_PROPBASER.IDbits.
