Arm
®
CoreLink™ GIC-600AE Generic Interrupt Controller
Technical Reference Manual
Document ID: 101206_0003_04_en
Issue: 04
Operation
INVALL commands
Error mnemonic Encoding IERR Stall Mask Description
INVALL_COLLECTION_OOR 0x10D03 0 1 CEE An INVALL has tried to invalidate an OOR collection. See
GITS_TYPER.
INVALL_UNMAPPED_COLLECTION 0x10D09 0 1 CEE An INVALL has tried to invalidate a collection that is not mapped
INVALL_TGT_OOR 0x10D20 1 0 - An INVALL has been sent to an illegal target
INVALL_CHIP_OFFLINE_OOR 0x10D22 1 0 - An INVALL has tried to invalidate an interrupt from a device that is
not mapped
INVALL_LPI_OFF 0x10D23 1 0 - An INVALL has been sent to a target that has LPIs turned off
INT commands
Error mnemonic Encoding IERR Stall Mask Description
INT_DEVICE_OOR 0x10301 0 1 UEE An incoming translation has attempted to use a device that is outside the
range that the ITS supports.
See GITS_BASER0, and for information about the supported range, see
GITS_TYPER.
INT_UNMAPPED_DEVICE 0x10304 0 1 UEE An incoming translation has tried to invalidate an interrupt from a device
that is not mapped
INT_ID_OOR 0x10305 0 1 UEE An INT has tried to use an EventID that is outside the size that the
corresponding MAPD command supports
INT_UNMAPPED_INTERRUPT 0x10307 0 1 UEE An INT command has tried to raise an interrupt that is not mapped
INT_ITE_INVALID 0x10310 0 1 UEE An INT command has tried to raise an interrupt with an EventID that is
not supported by the corresponding MAPD command
INT_TGT_OOR 0x10320 1 0 - INT received for a core that does not exist.
Software must correct mappings.
Interrupt is dropped and the target is reported in GICT_ERR<n>MISC1.
INT_CHIP_OFFLINE_OOR 0x10322 1 0 - INT received for a chip that is offline.
Software must either correct mappings or take the chip online.
Interrupt is dropped and TGT is reported in GICT_ERR<n>MISC1.
INT_LPI_OFF 0x10323 1 0 - INT received for a target with GICR_CTLR.Enable_LPIs disabled.
Software must either enable LPI or correct mappings.
Target is reported in GICT_ERR<n>MISC1.
INT_PHYSICALID_OOR 0x10326 1 0 - INT received with a physical ID that is beyond the range that is specified
in GICR_PROPBASER.IDbits.
Software must correct mappings.
Interrupt is dropped and ID is reported in GICT_ERR<n>MISC1.
Implementation-defined feature commands
Error mnemonic Encoding IERR Stall Mask Description
OPR_DEVICE_OOR 0x10A01 1 - - Software has tried an operation through GITS_OPR using a device that
is outside the range that the ITS supports.
See GITS_BASER0, and for information about the supported range,
see GITS_TYPER.
Copyright © 2018–2020, 2022 Arm Limited (or its affiliates). All rights reserved.
Non-Confidential
Page 85 of 268
