Cisco ASR 1004 Hardware Installation Guide

Behavior Description
Color —State
LEDLED Label
System failure or
powering up.
Red
Minor alarm indicator.AmberMinorMIN
Major alarm indicator.RedMajorMAJ
Critical alarm indicator.RedCriticalCRIT
Activity indicator.Flashing GreeneUSB0 FLASH(BootDiskBOOT
No activity.Off
Out of service or not
configured.
OffCARRIER
In frame and working
properly.
Green
Fault or loop condition.Amber
Link with no activity.Green10/100 /1000 RJ-45
Interface LED
LINK
Link with activity.Flashing Green
No link.Off
Port is not enabled.OffBuilt-in SPA SFP port
status
4 LEDs
Port enabled but there is
a problem with the
Ethernet link.
Amber
Port enabled, valid
Ethernet link
Green
All carrier card
requirements are within
specification.
GreenCarrier card powerPWR
Cisco ASR 1000 Series Router Hardware Installation Guide
45
Cisco ASR 1000 Series Routers Component Overview
Cisco Integrated ASR1000-RP1 for Cisco ASR 1002 Router

Cisco ASR 1004 Specifications

General

Product Type	Router
Form Factor	Rack-mountable
Rack Height	2U
Forwarding Capacity	Up to 20 Gbps
Total Number of Ports	Varies by configuration
Number of Total Expansion Slots	4
Product Series	ASR 1000
Model	ASR 1004
Forwarding Performance	Up to 20 Gbps
Operating System	Cisco IOS XE
Power Supply	Dual
Route Processor	ASR 1000 Series Route Processor
Network Interface Modules	SFP, SFP+, Gigabit Ethernet, 10 Gigabit Ethernet
Interfaces/Ports	Varies by configuration
Expansion Slot Type	SPA
Throughput	20 Gbps
Redundancy	Power supply, Route Processor
Interfaces	Gigabit Ethernet, 10 Gigabit Ethernet, SFP, SFP+
Storage	Up to 64 GB Flash
