Replacing the Pipette Assembly
DSX™ System Service Manual 7-11
4 Remove the Z-Drive Spring Cover (Part No. 22001010) by removing the two
M3 BHCS screws that secure the cover to the extrusion (Figure 7-8).
Spring
Cover
Figure 7-8 Removing the Spring Cover
