FOR-A HVS-390HS User Manual

192
RED TALLY-BLACK
Outputs a red tally when the specified signal is sent to the red
(tally color) bus.
RED TALLY-IN01 to 24
RED TALLY-STIL1 to 4
RED TALLY-STILK1 to 4
RED TALLY-MATT1 to 2
RED TALLY-ME1
RED TALLY-ME2
RED TALLY-ME1 PGM
RED TALLY-ME1 PREV
RED TALLY-ME1 CLN
RED TALLY-ME2 PGM
RED TALLY-ME2 PREV
RED TALLY-ME2 CLN
GREEN TALLY-BLACK
Outputs a green tally when the specified signal is sent to the
green (tally color) bus.
GREEN TALLY-IN01 to 24
GREEN TALLY-STIL1 to 4
GREEN TALLY-STILK1 to 4
GREEN TALLY-MATT1 to 2
GREEN TALLY-ME1
GREEN TALLY-ME2
GREEN TALLY-ME1 PGM
GREEN TALLY-ME1 PREV
GREEN TALLY-ME1 CLN
GREEN TALLY-ME2 PGM
GREEN TALLY-ME2 PREV
GREEN TALLY-ME2 CLN
COL1 to 6 TALLY-BLACK
Outputs a COLOR1 tally when the specified signal is sent to
the COLOR1 bus.
Outputs tallies in the same way as for COLOR2 to COLOR6.
COL1 to 6 TALLY-IN01 to 24
COL1 to 6 TALLY-STIL1 to 4
COL1 to 6 TALLY-STILK1 to 4
COL1 to 6 TALLY-MATT1 to 2
COL1 to 6 TALLY-ME1 to 2
COL1 to 6 TALLY-ME1 PGM
COL1 to 6 TALLY-ME1 PREV
COL1 to 6 TALLY-ME1 CLN
COL1 to 6 TALLY-ME2 PGM
COL1 to 6 TALLY-ME2 PREV
COL1 to 6 TALLY-ME2 CLN
M/E2 settings are only available if an HVS-39EXTME option card is installed.
