Still Directory Structure in the Main Unit
(Root) (still1)---------
still.tga
Still images for STILL1 are stored in JPEG, TGA and
BMP format. To send image files to STILL1, specify
this directory.
(still2)---------
still.tga
Still images for STILL2 are stored in JPEG, TGA and
BMP format. To send image files to STILL2, specify
this directory.
(still3)---------
still.tga
Still images for STILL3 are stored in JPEG, TGA and
BMP format. To send image files to STILL3, specify
this directory.
(still4)---------
still.tga
Still images for STILL4 are stored in JPEG, TGA and
BMP format. To send image files to STILL4, specify
this directory.
(clip1) Used for uploading movie files to STILL1.
(clip2) Used for uploading movie files to STILL2.
(clip3) Used for uploading movie files to STILL3.
(clip4) Used for uploading movie files to STILL4
(STILL_IN01) Used for uploading still image files (INPUT STILL) for IN01
(STILL_IN16) Used for uploading still image files (INPUT STILL) for IN16
(STILL_MEM1) Used for uploading still image files to MEM1 (Still backup memory).
(STILL_MEM6) Used for uploading still image files to MEM6 (Still backup memory).
(USB)
Used for uploading (editing) data to optional backup memory,
HVS-39MB (Displayed only when an HVS-39MB is installed.)
CLIP1
CLIP4
Used for uploading a backup movie clip (sequential
files) to STILL1 to 4. Each folder should contains
only one clip.
STILL1
STILL4
Used for uploading a backup image file to STILL1 to
4. Each folder should contains only one still image
file.
STILL_IN01
STILL_IN16
Used for uploading a backup image file for INPUT
STILL to IN01 to IN16. Each folder should contains
only one still image file.
* When uploading image or clip data to a USB sub folder in the HVS-39MB, its previous data must be
removed from the folder.
* For still images, refer to section 12. "Still Store." For clip operations, refer to section 13. "Managing Clips."
For INPUT STILL, refer to section 5-6. "INPUT STILL (Freezing Input Video)." For HVS-39MB, refer to
section 12-4. "Backing-up Still and Clip Data (HVS-39MB)."
* If a subfolder in the USB folder is accidentlly erased, reboot the switcher, a new subfolder will be created.
