50
HVS-30HSAI available format
System
standard
HD
Component
Composite
Component
SMPTE
Component
BetaCam
Component
1080/59.94i
720/59.94i
Available Available* Available Available* -
1080/50i,
720/50p
Available Available - - Available
525/60 - Available* Available Available* -
625/50 - Available - - Available
Other standards Available - - - -
* Video signals with and without 7.5% Setup can be accepted. If a signal with 7.5% Setup is input, the
symbol "+" follows immediately after the name of the signal.
(4) When operating in HD mode, SD signals can be input, upsized by using the Resize function
and used as HD signals. This function is available only when the SD signals have the same
frame rate as that of the current video format.
HVS-30HSDI/30HSAI
See 5-5. "Resize Function."
HVS-30PCIN
If 4:3 signals are input, the aspect ratio is selectable between two below.
RESIZE setting Description
NORMAL
Adds black bars to the left and right of the screen
.
FULL Expands the video image to 16:9 aspect ratio.
ZOOM
Displays image in full-screen by cropping off the top and bottom of the
image.
INPUT :SELECT :FORMAT :RESIZE : FS : 1/4
SIGNAL : =IN17 : =AUTO : =NORML: =OFF:
(FULL)
(ZOOM)
(4:3 image)
