Infineon TriCore TC1.6P User Manual

TriCore
®
TC1.6P & TC1.6E
32-bit Unified Processor Core
Instruction Set
V1.0 2013-07
User Manual (Volume 2) 3-64
Status Flags
Examples
call foobar
See Also
CALLA, CALLI, RET, FCALL, FRET
if (FCX == 0) trap(FCU);
if (PSW.CDE) then if(cdc_increment()) then trap(CDO);
PSW.CDE = 1;
ret_addr = PC + 2 ;
tmp_FCX = FCX;
EA = {FCX.FCXS, 6'b0, FCX.FCXO, 6'b0};
new_FCX = M(EA, word);
M(EA,16 * word) = {PCXI, PSW, A[10], A[11], D[8], D[9], D[10], D[11], A[12], A[13], A[14], A[15], D[12], D[13],
D[14], D[15]};
PCXI.PCPN = ICR.CCPN;
PCXI.PIE = ICR.IE;
PCXI.UL = 1;
PCXI[19:0] = FCX[19:0];
FCX[19:0] = new_FCX[19:0];
PC = PC + sign_ext(2 * disp8);
A[11] = ret_addr[31:0];
if (tmp_FCX == LCX) trap(FCD);
C Not changed by this instruction but read by the instruction.
V Not changed by this instruction but read by the instruction.
SV Not changed by this instruction but read by the instruction.
AV Not changed by this instruction but read by the instruction.
SAV Not changed by this instruction but read by the instruction.
call foobar
