Infineon TriCore TC1.6P User Manual

TriCore
®
TC1.6P & TC1.6E
32-bit Unified Processor Core
Instruction Set
V1.0 2013-07
User Manual (Volume 2) 3-134
JLEZ (16-bit)
Jump if Less Than or Equal to Zero (16-bit)
Description
JLEZD[b], disp4 (SBR)
Status Flags
Examples
See Also
JGEZ (16-bit), JGTZ (16-bit), JLTZ (16-bit), JNZ (16-bit), JZ (16-bit)
If the contents of D[b] are less than or equal to zero, then add the value specified by disp4, zero-extended and
multiplied by 2, to the contents of PC and jump to that address.
If (D[b] <= 0) then PC = PC + zero_ext(disp4) * 2;
C Not set by this instruction.
V Not set by this instruction.
SV Not set by this instruction.
AV Not set by this instruction.
SAV Not set by this instruction.
jlez d2, foobar
15
b
12 11
disp4
8 7
8E
H
0
