Infineon TriCore TC1.6P User Manual

TriCore
®
TC1.6P & TC1.6E
32-bit Unified Processor Core
Instruction Set
V1.0 2013-07
User Manual (Volume 2) 3-381
SWAPMSK.W
Swap under Mask
Description
The SWAPMSK.W instruction enables individual bits or bytes to be used as semaphore. Up to 32 semaphores
(bits) can be tested in parallel.
SWAPMSK.W uses an Extended register to provide both mask and swap data. It swaps through a mask the
contents of E[a][31:0] with the contents of the memory word specified by the addressing mode. Only those bits are
swapped where the corresponding bits in the mask E[a][63:32] are set. Register D[a] is unconditionally updated
with the contents of the memory word specified by the addressing mode.
SWAPMSK.WA[b], off10, E[a] (BO)(Base + Short Offset Addressing Mode)
EA = A[b] + sign_ext(off10);
tmp = M(EA, word);
M(EA, word) = (tmp & ~D[a+1]) | (D[a] & D[a+1]);
D[a] = tmp;
SWAPMSK.WP[b], E[a] (BO)(Bit-reverse Addressing Mode)
index = zero_ext(A[b+1][15:0]);
incr = zero_ext(A[b+1][31:16]);
EA = A[b] + index;
tmp = M(EA, word);
M(EA, word) = (tmp & ~D[a+1]) | (D[a] & D[a+1]);
D[a] = tmp;
new_index = reverse16(reverse16(index) + reverse16(incr));
A[b+1] = {incr[15:0], new_index[15:0]};
SWAPMSK.WP[b], off10, E[a] (BO)(Circular Addressing Mode)
index = zero_ext(A[b+1][15:0]);
length = zero_ext(A[b+1][31:16]);
EA = A[b] + index;
tmp = M(EA, word);
M(EA, word) = (tmp & ~D[a+1]) | (D[a] & D[a+1]);
D[a] = tmp;
new_index = index + sign_ext(off10);
31
off10[9:6]
28 27
22
H
22 21
off10[5:0]
16 15
b
12 11
a
8 7
49
H
0
31
-
28 27
02
H
22 21
-
16 15
b
12 11
a
8 7
69
H
0
31
off10[9:6]
28 27
12
H
22 21
off10[5:0]
16 15
b
12 11
a
8 7
69
H
0
