TriCore
®
TC1.6P & TC1.6E
32-bit Unified Processor Core
Instruction Set
V1.0 2013-07
User Manual (Volume 2) 3-377
SUBX
Subtract Extended
Description
Subtract the contents of data register D[b] from the contents of data register D[a] and put the result in data register
D[c]. The operands are treated as 32-bit integers. The PSW carry bit is set to the value of the ALU carry out.
SUBXD[c], D[a], D[b] (RR)
result = D[a] - D[b];
D[c] = result[31:0];
carry_out = carry(D[a],~D[b],1);
Status Flags
Examples
subx d3, d1, d2
See Also
SUB, SUBC, SUBS, SUBS.U
C PSW.C = carry_out;
V overflow = (result > 7FFFFFFF
H
) OR (result < -80000000
H
);
if (overflow) then PSW.V = 1 else PSW.V = 0;
SV if (overflow) then PSW.SV = 1 else PSW.SV = PSW.SV;
AV advanced_overflow = result[31] ^ result[30];
if (advanced_overflow) then PSW.AV = 1 else PSW.AV = 0;
SAV if (advanced_overflow) then PSW.SAV = 1 else PSW.SAV = PSW.SAV;
31
c
28 27
0C
H
20 19
-
18 17
-
16 15
b
12 11
a
8 7
0B
H
0
