Infineon TriCore TC1.6P - JL

To Next Page

To Previous Page

TriCore

TC1.6P & TC1.6E

32-bit Unified Processor Core

Instruction Set

V1.0 2013-07

User Manual (Volume 2) 3-132

Jump and Link

Description

Store the address of the next instruction in A[11] (return address). Add the value specified by disp24, sign-

extended and multiplied by 2, to the contents of PC and jump to that address.

JLdisp24 (B)

A[11] = PC + 4;

PC = PC + sign_ext(disp24) * 2;

Status Flags

Examples

jl foobar

See Also

J, JI, JA, JLA, JLI, CALLA, FCALL, FCALLA, LOOPU

C Not set by this instruction.

V Not set by this instruction.

SV Not set by this instruction.

AV Not set by this instruction.

SAV Not set by this instruction.

disp24[15:0]

16 15

disp24[23:16]

8 7
