Infineon TriCore TC1.6P - RSUBS - Reverse-Subtract with Saturation; RSUBS.U - Reverse-Subtract Unsigned with Saturation

TriCore
®
TC1.6P & TC1.6E
32-bit Unified Processor Core
Instruction Set
V1.0 2013-07
User Manual (Volume 2) 3-322
RSUBS
Reverse-Subtract with Saturation
RSUBS.U
Reverse-Subtract Unsigned with Saturation
Description
Subtract the contents of data register D[a] from the value const9 and put the result in data register D[c]. The
operands are treated as signed (RSUBS) or unsigned (RSUBS.U) 32-bit integers, with saturation on signed
(RSUBS) or unsigned (RSUBS.U) overflow. The value const9 is sign-extended before the operation is performed.
RSUBSD[c], D[a], const9 (RC)
result = sign_ext(const9) - D[a];
D[c] = ssov(result, 32);
RSUBS.UD[c], D[a], const9 (RC)
result = sign_ext(const9) - D[a]; // unsigned
D[c] = suov(result, 32);
Status Flags
Examples
rsubs d3, d1, #126
rsubs.u d3, d1, #126
See Also
RSUB
C Not set by these instructions.
V signed:
overflow = (result > 7FFFFFFF
H
) OR (result < -80000000
H
);
if (overflow) then PSW.V = 1 else PSW.V = 0;
unsigned:
overflow = (result > FFFFFFFF
H
) OR (result < 00000000
H
);
if (overflow) then PSW.V = 1 else PSW.V = 0;
SV if (overflow) then PSW.SV = 1 else PSW.SV = PSW.SV;
AV advanced_overflow = result[31] ^ result[30];
if (advanced_overflow) then PSW.AV = 1 else PSW.AV = 0;
SAV if (advanced_overflow) then PSW.SAV = 1 else PSW.SAV = PSW.SAV;
31
c
28 27
0A
H
21 20
const9
12 11
a
8 7
8B
H
0
31
c
28 27
0B
H
21 20
const9
12 11
a
8 7
8B
H
0
