TriCore

TC1.6P & TC1.6E

32-bit Unified Processor Core

Instruction Set

V1.0 2013-07

User Manual (Volume 2) 3-94

ENABLE

Enable Interrupts

Description

Note:ENABLE can only be executed in User-1 or Supervisor mode.

Enable interrupts by setting the Interrupt Enable bit (ICR.IE) in the Interrupt Control Register (ICR) to one.

ENABLE(SYS)

ICR.IE = 1;

Status Flags

Examples

enable

See Also

BISR, DISABLE, RESTORE

C Not set by this instruction.

V Not set by this instruction.

SV Not set by this instruction.

AV Not set by this instruction.

SAV Not set by this instruction.

28 27

22 21

12 11

8 7
