TriCore
®
TC1.6P & TC1.6E
32-bit Unified Processor Core
Instruction Set
V1.0 2013-07
User Manual (Volume 2) 3-141
JNE.A
Jump if Not Equal Address
Description
If the contents of A[a] are not equal to the contents of A[b] then add the value specified by disp15, sign-extended
and multiplied by 2, to the contents of PC and jump to that address.
JNE.AA[a], A[b], disp15 (BRR)
if (A[a] != A[b]) then PC = PC + sign_ext(disp15) * 2;
Status Flags
Examples
jne.a a4, a2, foobar
See Also
JEQ.A
C Not set by this instruction.
V Not set by this instruction.
SV Not set by this instruction.
AV Not set by this instruction.
SAV Not set by this instruction.
31
01
H
30
disp15
16 15
b
12 11
a
8 7
7D
H
0
