TriCore
®
TC1.6P & TC1.6E
32-bit Unified Processor Core
Instruction Set
V1.0 2013-07
User Manual (Volume 2) 3-378
SVLCX
Save Lower Context
Description
Store the contents of registers A[2] to A[7], D[0] to D[7], A[11] (return address) and PCXI, to the memory location
pointed to by the FCX register. This operation saves the lower context of the currently executing task.
SVLCX(SYS)
if (FCX == 0) trap(FCU);
tmp_FCX = FCX;
EA = {FCX.FCXS, 6'b0, FCX.FCXO, 6'b0};
new_FCX = M(EA, word);
M(EA, 16 * word) = {PCXI, A[11], A[2], A[3], D[0], D[1], D[2], D[3], A[4], A[5], A[6], A[7], D[4], D[5], D[6], D[7]};
PCXI.PCPN = ICR.CCPN
PCXI.PIE = ICR.IE;
PCXI.UL = 0;
PCXI[19:0] = FCX[19:0];
FCX[19:0] = new_FCX[19:0];
if (tmp_FCX == LCX) trap(FCD);
Status Flags
Examples
svlcx
See Also
LDLCX, LDUCX, RSLCX, STLCX, STUCX, BISR
C Not set by this instruction.
V Not set by this instruction.
SV Not set by this instruction.
AV Not set by this instruction.
SAV Not set by this instruction.
31
-
28 27
08
H
22 21
-
12 11
-
8 7
0D
H
0
