JNZ (16-bit)
Jump if Not Equal to Zero (16-bit)
Description
JNZD[15], disp8 (SB)
JNZD[b], disp4 (SBR)
Status Flags
Examples
See Also
JGEZ (16-bit), JGTZ (16-bit), JLEZ (16-bit), JLTZ (16-bit), JZ (16-bit)
If contents of either D[b] (instruction format SBR) or D[15] (instruction format SB) are not equal to zero, then add
value specified by either disp4 (format SBR) or disp8 (format SB), zero-extended (disp4) or sign-extended (disp8)
and multiplied by 2, to the contents of PC and jump to that address.
if (D[15] != 0) then PC = PC + sign_ext(disp8) * 2;
if (D[b] != 0) then PC = PC + zero_ext(disp4) * 2;
C Not set by this instruction.
V Not set by this instruction.
SV Not set by this instruction.
AV Not set by this instruction.
SAV Not set by this instruction.
jnz d2, foobar
jnz d15, foobar
15
disp8
8 7
EE
H
0
15
b
12 11
disp4
8 7
F6
H
0
