Page #389 background image
TriCore
®
TC1.6P & TC1.6E
32-bit Unified Processor Core
Instruction Set
V1.0 2013-07
User Manual (Volume 2) 3-342
SHA.H
Arithmetic Shift Packed Half-words
Description
If the shift count specified through the contents of either D[b] (instruction format RR) or const9 (instruction format
RC) is greater than or equal to zero, then left-shift each half-word in D[a] by the amount specified by shift count.
The vacated bits are filled with zeros and bits shifted out are discarded. If the shift count is less than zero, right-
shift each half-word in D[a] by the absolute value of the shift count. The vacated bits are filled with the sign-bit (the
most significant bit) of the respective half-word, and bits shifted out are discarded. Put the result in D[c]. Note that
for the shifts, each half-word is treated individually, and bits shifted out of a half-word are not shifted into the next
half-word.
The shift count is a signed number, derived from the sign-extension of either D[b][4:0] (format RR) or const9[4:0]
(format RC).
The range for the shift count is -16 to +15. The result for each half-word for a shift count of -16 is either all zeros
or all ones, depending on the sign-bit of the respective half-word.
SHA.HD[c], D[a], const9 (RC)
if (const9[4:0] >= 0) then {
result_halfword0 = D[a][15:0] << const9[4:0];
result_halfword1 = D[a][31:16] << const9[4:0];
} else {
shift_count = 0 - const9[4:0];
msk = D[a][31] ? (((1 << shift_count) - 1) << (16 - shift_count)) : 0;
result = msk | (D[a] >> shift_count);
result_halfword0 = msk | (D[a][15:0] >> shift_count);
result_halfword1 = msk | (D[a][31:16] >> shift_count);
}
D[c][15:0] = result_halfword0[15:0];
D[c][31:16] = result_halfword1[15:0];
SHA.HD[c], D[a], D[b] (RR)
if (D[b][4:0] >= 0) then {
result_halfword0 = D[a][15:0] << D[b][4:0];
result_halfword1 = D[a][31:16] << D[b][4:0];
} else {
shift_count = 0 - D[b][4:0];
msk = D[a][31] ? (((1 << shift_count) - 1) << (16 - shift_count)) : 0;
result_halfword0 = msk | (D[a][15:0] >> shift_count);
result_halfword1 = msk | (D[a][31:16] >> shift_count);
31
c
28 27
41
H
21 20
const9
12 11
a
8 7
8F
H
0
31
c
28 27
41
H
20 19
-
18 17
-
16 15
b
12 11
a
8 7
0F
H
0
