CACHEA.WI
Cache Address, Writeback and Invalidate
Description
If the cache line containing the byte memory location specified by the addressing mode is present in the L1 data
cache, write back any modified data and then invalidate the line in the L1 data cache.
If the cache line containing the byte memory location specified by the addressing mode is not present in the L1
data cache then no operation should be performed in the L1 data cache. Specifically a refill of the line containing
the byte pointed to by the effective address should not be performed. Any address register updates associated
with the addressing mode are always performed regardless of the cache operation. The effective address is a
virtual address when operating in virtual mode.
CACHEA.WIA[b], off10 (BO)(Base + Short Offset Addressing Mode)
EA = A[b] + sign_ext(off10);
cache_address_wi(EA);
CACHEA.WIP[b] (BO)(Bit-reverse Addressing Mode)
index = zero_ext(A[b+1][15:0]);
incr = zero_ext(A[b+1][31:16]);
EA = A[b] + index;
cache_address_wi(EA);
new_index = reverse16(reverse16(index) + reverse16(incr));
A[b+1] = {incr[15:0], new_index[15:0]};
CACHEA.WIP[b], off10 (BO) (Circular Addressing Mode)
index = zero_ext(A[b+1][15:0]);
length = zero_ext(A[b+1][31:16]);
EA = A[b] + index;
cache_address_wi(EA);
new_index = index + sign_ext(off10);
new_index = new_index < 0 ? new_index + length : new_index % length;
A[b+1] = {length[15:0], new_index[15:0]};
CACHEA.WIA[b], off10 (BO)(Post-increment Addressing Mode)
31
off10[9:6]
28 27
2D
H
22 21
off10[5:0]
16 15
b
12 11
-
8 7
89
H
0
31
-
28 27
0D
H
22 21
-
16 15
b
12 11
-
8 7
A9
H
0
31
off10[9:6]
28 27
1D
H
22 21
off10[5:0]
16 15
b
12 11
-
8 7
A9
H
0
