Infineon TriCore TC1.6P User Manual

TriCore
®
TC1.6P & TC1.6E
32-bit Unified Processor Core
Instruction Set
V1.0 2013-07
User Manual (Volume 2) 3-275
MUL.H
Packed Multiply Q Format
Description
Multiply two signed 16-bit (half-word) values and put the product (left justified if n == 1) into a 32-bit register. Note
that since there are two results both halves of an extended data register are used. There are four cases of half-
word multiplication:
• 16U * 16U, 16L * 16L
• 16U * 16L, 16L * 16U
• 16U * 16L, 16L * 16L
• 16L * 16U, 16U * 16U
Note that n should only take the values 0 or 1, any other value returns an undefined result. If (n == 1) then 8000
H
* 8000
H
= 7FFFFFFF
H
(for signed 16-bit * 16-bit multiplications only).
MUL.HE[c], D[a], D[b] LL, n (RR1)
(16U * 16L || 16L * 16L) --> 32||32
sc1 = (D[a][31:16] == 8000
H
) AND (D[b][15:0] == 8000
H
) AND (n == 1);
sc0 = (D[a][15:0] == 8000
H
) AND (D[b][15:0] == 8000
H
) AND (n == 1);
result_word1 = sc1 ? 7FFFFFFF
H
: ((D[a][31:16] * D[b][15:0]) << n);
result_word0 = sc0 ? 7FFFFFFF
H
: ((D[a][15:0] * D[b][15:0]) << n);
E[c] = {result_word1[31:0], result_word0[31:0]}; // Packed fraction
MUL.HE[c], D[a], D[b] LU, n (RR1)
(16U * 16L || 16L * 16U) --> 32||32
sc1 = (D[a][31:16] == 8000
H
) AND (D[b][15:0] == 8000
H
) AND (n == 1);
sc0 = (D[a][15:0] == 8000
H
) AND (D[b][31:16] == 8000
H
) AND (n == 1);
result_word1 = sc1 ? 7FFFFFFF
H
: ((D[a][31:16] * D[b][15:0]) << n);
result_word0 = sc0 ? 7FFFFFFF
H
: ((D[a][15:0] * D[b][31:16]) << n);
E[c] = {result_word1[31:0], result_word0[31:0]}; // Packed fraction
MUL.HE[c], D[a], D[b] UL, n (RR1)
(16U * 16U || 16L * 16L) --> 32||32
sc1 = (D[a][31:16] == 8000
H
) AND (D[b][31:16] == 8000
H
) AND (n == 1);
sc0 = (D[a][15:0] == 8000
H
) AND (D[b][15:0] == 8000
H
) AND (n == 1);
result_word1 = sc1 ? 7FFFFFFF
H
: ((D[a][31:16] * D[b][31:16]) << n);
result_word0 = sc0 ? 7FFFFFFF
H
: ((D[a][15:0] * D[b][15:0]) << n);
31
c
28 27
1A
H
18 17
n
16 15
b
12 11
a
8 7
B3
H
0
31
c
28 27
19
H
18 17
n
16 15
b
12 11
a
8 7
B3
H
0
31
c
28 27
18
H
18 17
n
16 15
b
12 11
a
8 7
B3
H
0
