TriCore

TC1.6P & TC1.6E

32-bit Unified Processor Core

Instruction Set

RESTORE

Restore

Description

Restore the Interrupt Enable bit (ICR.IE) to the value saved in D[a][0].

RESTORE can only be executed in User-1 or Supervisor mode.

RESTORED[a] (SYS)

V1.0 2013-07

User Manual (Volume 2) 3-313

ICR.IE = D[a][0];

Status Flags

Examples

restore d7

See Also

DISABLE, ENABLE

C Not set by this instruction.

V Not set by this instruction.

SV Not set by this instruction.

AV Not set by this instruction.

SAV Not set by this instruction.

28 27

22 21

12 11

8 7
