Infineon TriCore TC1.6P - JA - Jump Unconditional Absolute

To Next Page

To Previous Page

TriCore

TC1.6P & TC1.6E

32-bit Unified Processor Core

Instruction Set

Jump Unconditional Absolute

Description

Load the value specified by disp24 into PC and jump to that address.

The value disp24 is used to form the Effective Address (EA).

JAdisp24 (B)

V1.0 2013-07

User Manual (Volume 2) 3-123

PC = {disp24[23:20], 7’b0000000, disp24[19:0], 1’b0};

Status Flags

Examples

ja foobar

See Also

J, JI, JL, JLA, JLI, LOOPU

C Not set by this instruction.

V Not set by this instruction.

SV Not set by this instruction.

AV Not set by this instruction.

SAV Not set by this instruction.

disp24[15:0]

16 15

disp24[23:16]

8 7
