User Manual (Volume 2) 3-294
NOR
Bitwise NOR
Description
Compute the bitwise NOR of the contents of data register D[a] and the contents of either data register D[b]
(instruction format RR) or const9 (instruction format RC) and put the result in data register D[c]. The const9 value
is zero-extended.
NORD[c], D[a], const9 (RC)
D[c] = ~(D[a] | zero_ext(const9));
NORD[c], D[a], D[b] (RR)
D[c] = ~(D[a] | D[b]);
Status Flags
Examples
nor d3, d1, d2
nor d3, d1, #126
See Also
AND, ANDN, NAND, NOT (16-bit), OR, ORN, XNOR, XOR
C Not set by this instruction.
V Not set by this instruction.
SV Not set by this instruction.
AV Not set by this instruction.
SAV Not set by this instruction.
31
c
28 27
0B
H
21 20
const9
12 11
a
8 7
8F
H
0
31
c
28 27
0B
H
20 19
-
18 17
-
16 15
b
12 11
a
8 7
0F
H
0
