TriCore

TC1.6P & TC1.6E

32-bit Unified Processor Core

Instruction Set

V1.0 2013-07

User Manual (Volume 2) 3-234

MOVH

Move High

Description

Move the value const16 to the most-significant half-word of data register D[c] and set the least-significant 16-bits

to zero.

MOVHD[c], const16 (RLC)

D[c] = {const16, 16’h0000};

Status Flags

Examples

movh d3, #526

See Also

MOV, MOV.U

C Not set by this instruction.

V Not set by this instruction.

SV Not set by this instruction.

AV Not set by this instruction.

SAV Not set by this instruction.

28 27

const16

12 11

8 7
