Infineon TriCore TC1.6P User Manual

TriCore
®
TC1.6P & TC1.6E
32-bit Unified Processor Core
Instruction Set
V1.0 2013-07
User Manual (Volume 2) 3-346
ST.A
Store Word from Address Register
Description
Store the value in address register A[a] to the memory location specified by the addressing mode.
Note:If the source register is modified by the addressing mode, the value stored to memory is undefinded.
ST.Aoff18, A[a] (ABS)(Absolute Addressing Mode)
EA = {off18[17:14], 14b'0, off18[13:0]};
M(EA, word) = A[a];
ST.AA[b], off10, A[a] (BO)(Base + Short Offset Addressing Mode)
EA = A[b] + sign_ext(off10);
M(EA, word) = A[a];
ST.AP[b], A[a] (BO)(Bit-reverse Addressing Mode)
index = zero_ext(A[b+1][15:0]);
incr = zero_ext(A[b+1][31:16]);
EA = A[b] + index;
M(EA, word) = A[a];
new_index = reverse16(reverse16(index) + reverse16(incr));
A[b+1] = {incr[15:0], new_index[15:0]};
ST.AP[b], off10, A[a] (BO)(Circular Addressing Mode)
index = zero_ext(A[b+1][15:0]);
length = zero_ext(A[b+1][31:16]);
EA = A[b] + index;
M(EA, word) = A[a];
new_index = index + sign_ext(off10);
Store the value in address register A[a] (instruction format BO, SSR, SSRO or SSR) or A[15] (instruction format
SRO or SC) to the memory location specified by the addressing mode.
Note:If the source register is modified by the addressing mode, the value stored to memory is undefinded.
31
off18[9:6]
28 27
02
H
26 25
off18[13:10]
22 21
off18[5:0]
16 15
off18[17:14]
12 11
a
8 7
A5
H
0
31
off10[9:6]
28 27
26
H
22 21
off10[5:0]
16 15
b
12 11
a
8 7
89
H
0
31
-
28 27
06
H
22 21
-
16 15
b
12 11
a
8 7
A9
H
0
31
off10[9:6]
28 27
16
H
22 21
off10[5:0]
16 15
b
12 11
a
8 7
A9
H
0
