TriCore

TC1.6P & TC1.6E

32-bit Unified Processor Core

Instruction Set

V1.0 2013-07

User Manual (Volume 2) 3-72

CLZ

Count Leading Zeros

Description

Count the number of consecutive zeros in D[a] starting with bit 31, and put result in D[c].

CLZD[c], D[a] (RR)

result = leading_zeros(D[a]);

D[c] = zero_ext(result);

Status Flags

Examples

clz d3, d1

See Also

CLO, CLO.H, CLS, CLS.H, CLZ.H

C Not set by this instruction.

V Not set by this instruction.

SV Not set by this instruction.

AV Not set by this instruction.

SAV Not set by this instruction.

28 27

20 19

18 17

16 15

12 11

8 7
