Infineon TriCore TC1.6P User Manual

TriCore
®
TC1.6P & TC1.6E
32-bit Unified Processor Core
Instruction Set
V1.0 2013-07
User Manual (Volume 2) 3-76
CMPSWAP.W
Compare and Swap
Description
The CMPSWAP.W instruction conditionally swaps the data register D[a] and the contents of the memory word
specified by the addressing mode.
If the contents of the memory word specified by the addressing mode is equal to the contents of register D[a+1]
then swap the contents of the memory word with the register D[a]. Register D[a] is unconditionally updated with
the contents of the memory word specified by the addressing mode.
CMPSWAP.WA[b], off10, E[a] (BO)(Base + Short Offset Addressing Mode)
EA = A[b] + sign_ext(off10);
tmp = M(EA, word);
M(EA, word) = (tmp == D[a+1]) ? D[a] : tmp;
D[a] = tmp;
CMPSWAP.WP[b], E[a] (BO)(Bit-reverse Addressing Mode)
index = zero_ext(A[b+1][15:0]);
incr = zero_ext(A[b+1][31:16]);
EA = A[b] + index;
tmp = M(EA, word);
M(EA, word) = (tmp == D[a+1]) ? D[a] : tmp;
D[a] = tmp;
new_index = reverse16(reverse16(index) + reverse16(incr));
A[b+1] = {incr[15:0], new_index[15:0]};
CMPSWAP.WP[b], off10, E[a] (BO)(Circular Addressing Mode)
index = zero_ext(A[b+1][15:0]);
length = zero_ext(A[b+1][31:16]);
EA = A[b] + index;
tmp = M(EA, word);
M(EA, word) = (tmp == D[a+1]) ? D[a] : tmp;
D[a] = tmp;
new_index = index + sign_ext(off10);
new_index = new_index < 0 ? new_index + length : new_index % length;
31
off10[9:6]
28 27
23
H
22 21
off10[5:0]
16 15
b
12 11
a
8 7
49
H
0
31
-
28 27
03
H
22 21
-
16 15
b
12 11
a
8 7
69
H
0
31
off10[9:6]
28 27
13
H
22 21
off10[5:0]
16 15
b
12 11
a
8 7
69
H
0
