Infineon TriCore TC1.6P - J - Jump Unconditional

To Next Page

To Previous Page

TriCore

TC1.6P & TC1.6E

32-bit Unified Processor Core

Instruction Set

V1.0 2013-07

User Manual (Volume 2) 3-122

Jump Unconditional

Description

Add the value specified by disp24, sign-extended and multiplied by 2, to the contents of PC and jump to that

address.

Jdisp24 (B)

PC = PC + sign_ext(disp24) * 2;

Jdisp8 (SB)

Status Flags

Examples

j foobar

See Also

JA, JI, JL, JLA, JLI, LOOPU

Add the value specified by disp8, sign-extended and multiplied by 2, to the contents of PC and jump to that

address.

PC = PC + sign_ext(disp8) * 2;

C Not set by this instruction.

V Not set by this instruction.

SV Not set by this instruction.

AV Not set by this instruction.

SAV Not set by this instruction.

j foobar

disp24[15:0]

16 15

disp24[23:16]

8 7

disp8

8 7
