Infineon TriCore TC1.6P User Manual

TriCore
®
TC1.6P & TC1.6E
32-bit Unified Processor Core
Instruction Set
V1.0 2013-07
User Manual (Volume 2) 3-249
MSUB.U
Multiply-Subtract Unsigned
MSUBS.U
Multiply-Subtract Unsigned, Saturated
Description
Multiply two unsigned 32-bit integers. Subtract the product from an unsigned 32-bit or 64-bit integer and put the
result into a 32-bit or 64-bit register. The value const9 is zero-extended before the multiplication is performed. The
MSUBS.U results are saturated on overflow.
MSUB.UE[c], E[d], D[a], const9 (RCR)
64 - (32 * K9) --> 64 unsigned
result = E[d] - (D[a] * zero_ext(const9)); // unsigned operators
E[c] = result[63:0];
MSUB.UE[c], E[d], D[a], D[b] (RRR2)
64 - (32 * 32) --> 64 unsigned
result = E[d] - (D[a] * D[b]); // unsigned operators
E[c] = result[63:0];
MSUBS.UD[c], D[d], D[a], const9 (RCR)
32 - (32 * K9) --> 32 unsigned saturated
result = D[d] - (D[a] * zero_ext(const9)); // unsigned operators
D[c] = suov(result, 32);
MSUBS.UE[c], E[d], D[a], const9 (RCR)
64 - (32 * K9) --> 64 unsigned saturated
result = E[d] - (D[a] * zero_ext(const9)); // unsigned operators
E[c] = suov(result, 64);
MSUBS.UD[c], D[d], D[a], D[b] (RRR2)
32 - (32 * 32) --> 32 unsigned saturated
31
c
28 27
d
24 23
02
H
21 20
const9
12 11
a
8 7
33
H
0
31
c
28 27
d
24 23
68
H
16 15
b
12 11
a
8 7
23
H
0
31
c
28 27
d
24 23
04
H
21 20
const9
12 11
a
8 7
33
H
0
31
c
28 27
d
24 23
06
H
21 20
const9
12 11
a
8 7
33
H
0
