TriCore

TC1.6P & TC1.6E

32-bit Unified Processor Core

Instruction Set

MOV.U

Move Unsigned

Description

Move the zero-extended value const16 to data register D[c].

MOV.UD[c], const16 (RLC)

V1.0 2013-07

User Manual (Volume 2) 3-233

D[c] = zero_ext(const16);

Status Flags

Examples

mov.u d3, #526

See Also

MOV, MOVH

C Not set by this instruction.

V Not set by this instruction.

SV Not set by this instruction.

AV Not set by this instruction.

SAV Not set by this instruction.

28 27

const16

12 11

8 7
