Infineon TriCore TC1.6P User Manual

TriCore
®
TC1.6P & TC1.6E
32-bit Unified Processor Core
Instruction Set
V1.0 2013-07
User Manual (Volume 2) 3-393
XOR.GE
Greater Than or Equal Accumulating
XOR.GE.U
Greater Than or Equal Accumulating Unsigned
Description
Calculate the logical XOR of D[c][0] and the Boolean result of the GE or GE.U operation on the contents of data
register D[a] and either data register D[b] (instruction format RR) or const9 (instruction format RC). Put the result
in D[c][0]. All other bits in D[c] are unchanged. D[a] and D[b] are treated as 32-bit signed (XOR.GE) or unsigned
(XOR.GE.U) integers. The value const9 is sign-extended (XOR.GE) or zero-extended (XOR.GE.U).
XOR.GED[c], D[a], const9 (RC)
D[c] = {D[c][31:1], D[c][0] XOR (D[a] >= sign_ext(const9))};
XOR.GED[c], D[a], D[b] (RR)
D[c] = {D[c][31:1], D[c][0] XOR (D[a] >= D[b])};
XOR.GE.UD[c], D[a], const9 (RC)
D[c] = {D[c][31:1], D[c][0] XOR (D[a] >= zero_ext(const9))}; // unsigned
XOR.GE.UD[c], D[a], D[b] (RR)
D[c] = {D[c][31:1], D[c][0] XOR (D[a] >= D[b])}; // unsigned
Status Flags
Examples
xor.ge d3, d1, d2
xor.ge d3, d1, #126
C Not set by these instructions.
V Not set by these instructions.
SV Not set by these instructions.
AV Not set by these instructions.
SAV Not set by these instructions.
31
c
28 27
33
H
21 20
const9
12 11
a
8 7
8B
H
0
31
c
28 27
33
H
20 19
-
18 17
-
16 15
b
12 11
a
8 7
0B
H
0
31
c
28 27
34
H
21 20
const9
12 11
a
8 7
8B
H
0
31
c
28 27
34
H
20 19
-
18 17
-
16 15
b
12 11
a
8 7
0B
H
0
