TriCore
®
TC1.6P & TC1.6E
32-bit Unified Processor Core
Instruction Set
V1.0 2013-07
User Manual (Volume 2) 3-338
SH.AND.T
Accumulating Shift-AND
SH.ANDN.T
Accumulating Shift-AND-Not
SH.NAND.T
Accumulating Shift-NAND
SH.NOR.T
Accumulating Shift-NOR
SH.OR.T
Accumulating Shift-OR
SH.ORN.T
Accumulating Shift-OR-Not
SH.XNOR.T
Accumulating Shift-XNOR
SH.XOR.T
Accumulating Shift-XOR
Description
Left shift D[c] by one. The bit shifted out is discarded. Compute the logical operation (AND, ANDN, NAND, NOR,
OR, ORN, XNOR or XOR) of the value of bit pos1 of data register D[a], and bit pos2 of D[b]. Put the result in D[c][0].
SH.AND.TD[c], D[a], pos1, D[b], pos2 (BIT)
D[c] = {D[c][30:0], (D[a][pos1] AND D[b][pos2])};
SH.ANDN.TD[c], D[a], pos1, D[b], pos2 (BIT)
D[c] = {D[c][30:0], (D[a][pos1] AND !(D[b][pos2]))};
SH.NAND.TD[c], D[a], pos1, D[b], pos2 (BIT)
D[c] = {D[c][30:0], !(D[a][pos1] AND D[b][pos2])};
SH.NOR.TD[c], D[a], pos1, D[b], pos2 (BIT)
D[c] = {D[c][30:0], !(D[a][pos1] OR D[b][pos2])};
31
c
28 27
pos2
23 22
00
H
21 20
pos1
16 15
b
12 11
a
8 7
27
H
0
31
c
28 27
pos2
23 22
03
H
21 20
pos1
16 15
b
12 11
a
8 7
27
H
0
31
c
28 27
pos2
23 22
00
H
21 20
pos1
16 15
b
12 11
a
8 7
A7
H
0
31
c
28 27
pos2
23 22
02
H
21 20
pos1
16 15
b
12 11
a
8 7
27
H
0
