DIV
Divide
DIV.U
Divide Unsigned
Description
Divide the contents of register D[a] by the contents of register D[b]. Put the resulting quotient in E[c][31:0] and the
remainder in E[c][63:32].
The operands and results are treated as signed 32-bit integers for the DIV instruction and as unsigned 32-bit
integers for the DIV.U instruction.
Overflow occurs if the divisor (D[b]) is zero. For DIV, Overflow also occurs if the dividend (D[a]) is the maximum
negative number and the divisor is minus 1.
DIVE[c], D[a], D[b] (RR)
dividend = D[a];
divisor = D[b];
if (divisor == 0) then {
if (dividend >= 0) then {
quotient = 0x7fffffff;
remainder = 0x00000000;
} else {
quotient = 0x80000000;
remainder = 0x00000000;
}
} else if ((divisor == 0xffffffff) AND (dividend == 0x80000000)) then {
quotient = 0x7fffffff;
remainder = 0x00000000;
} else {
remainder = dividend % divisor
quotient = (dividend - remainder)/divisor
}
E[c][31:0] = quotient;
E[c][63:32] = remainder;
DIV.UE[c], D[a], D[b] (RR)
dividend = D[a];
divisor = D[b];
31
c
28 27
20
H
20 19
-
18 17
1
H
16 15
b
12 11
a
8 7
4B
H
0
31
c
28 27
21
H
20 19
-
18 17
1
H
16 15
b
12 11
a
8 7
4B
H
0
