Infineon TriCore TC1.6P User Manual

TriCore
®
TC1.6P & TC1.6E
32-bit Unified Processor Core
Instruction Set
V1.0 2013-07
User Manual (Volume 2) 3-225
MIN.B
Minimum Value Packed Byte
MIN.BU
Minimum Value Packed Byte Unsigned
Description
Compute the minimum value of the corresponding bytes in D[a] and D[b] and put each result in the corresponding
byte of D[c]. The operands are treated as either signed (MIN.B) or unsigned (MIN.BU), 8-bit integers.
MIN.BD[c], D[a], D[b] (RR)
D[c][31:24] = (D[a][31:24] < D[b][31:24]) ? D[a][31:24] : D[b][31:24];
D[c][23:16] = (D[a][23:16] < D[b][23:16]) ? D[a][23:16] : D[b][23:16];
D[c][15:8] = (D[a][15:8] < D[b][15:8]) ? D[a][15:8] : D[b][15:8];
D[c][7:0] = (D[a][7:0] < D[b][7:0]) ? D[a][7:0] : D[b][7:0];
MIN.BUD[c], D[a], D[b] (RR)
D[c][31:24] = (D[a][31:24] < D[b][31:24]) ? D[a][31:24] : D[b][31:24]; // unsigned
D[c][23:16] = (D[a][23:16] < D[b][23:16]) ? D[a][23:16] : D[b][23:16]; // unsigned
D[c][15:8] = (D[a][15:8] < D[b][15:8]) ? D[a][15:8] : D[b][15:8]; // unsigned
D[c][7:0] = (D[a][7:0] < D[b][7:0]) ? D[a][7:0] : D[b][7:0]; // unsigned
Status Flags
Examples
min.b d3, d1, d2
min.bu d3, d1, d2
See Also
MAX.B, MAX.BU, MAX.H, MAX.HU, MIN.H, MIN.HU
C Not set by these instructions.
V Not set by these instructions.
SV Not set by these instructions.
AV Not set by these instructions.
SAV Not set by these instructions.
31
c
28 27
58
H
20 19
-
18 17
-
16 15
b
12 11
a
8 7
0B
H
0
31
c
28 27
59
H
20 19
-
18 17
-
16 15
b
12 11
a
8 7
0B
H
0
