ISYNC

Synchronize Instructions

Description

The ISYNC instruction forces completion of all previous instructions, then flushes the CPU pipelines and

invalidates any cached pipeline state before proceeding to the next instruction.

Note:I-cache is not invalidated by ISYNC.

Note:An ISYNC instruction should follow a MTCR instruction. This ensures that all instructions following the

MTCR see the effects of the CSFR update.

ISYNC(SYS)

Status Flags

Examples

isync

See Also

DSYNC

C Not set by this instruction.

V Not set by this instruction.

SV Not set by this instruction.

AV Not set by this instruction.

SAV Not set by this instruction.

28 27

22 21

12 11

8 7
