Infineon TriCore TC1.6P User Manual

TriCore
®
TC1.6P & TC1.6E
32-bit Unified Processor Core
Instruction Set
V1.0 2013-07
User Manual (Volume 2) 3-177
LT
Less Than
LT.U
Less Than Unsigned
Description
If the contents of data register D[a] are less than the contents of either data register D[b] (instruction format RR)
or const9 (instruction format RC), then set the least-significant bit of D[c] to one and clear the remaining bits to
zero; otherwise clear all bits in D[c].
The operands are treated as signed (LT) or unsigned (LT.U) integers. The const9 value is sign-extended (LT) or
zero-extended (LT.U).
LTD[c], D[a], const9 (RC)
result = (D[a] < sign_ext(const9));
D[c] = zero_ext(result);
LTD[c], D[a], D[b] (RR)
result = (D[a] < D[b]);
D[c] = zero_ext(result);
LTD[15], D[a], const4 (SRC)
LTD[15], D[a], D[b] (SRR)
If the contents of data register D[a] are less than the contents of either data register D[b] (instruction format SRR)
or const4 (instruction format SRC), set the least-significant bit of D[15] to one and clear the remaining bits to zero;
otherwise clear all bits in D[15]. The operands are treated as signed 32-bit integers, and the const4 value is sign-
extended.
result = (D[a] < sign_ext(const4));
D[15] = zero_ext(result);
result = (D[a] < D[b]);
D[15] = zero_ext(result);
31
c
28 27
12
H
21 20
const9
12 11
a
8 7
8B
H
0
31
c
28 27
12
H
20 19
-
18 17
-
16 15
b
12 11
a
8 7
0B
H
0
15
const4
12 11
a
8 7
FA
H
0
15
b
12 11
a
8 7
7A
H
0
