INSERT
Insert Bit Field
Description
Starting at bit zero, extract from either D[b] (instruction formats RRRR, RRRW, RRPW) or const4 (instruction
formats RCRR, RCRW, RCPW) the number of consecutive bits specified by either E[d][36:32] (formats RRRR,
RCRR) or width (formats RRRW, RRPW, RCRW, RCPW).
Shift the result left by the number of bits specified by either E[d][4:0] (formats RRRR, RCRR), D[d] (formats RRRW,
RCRW) or pos (formats RRPW, RCPW); extract a copy of D[a], clearing the bits starting at the bit position specified
by either E[d][4:0] (formats RRRR, RCRR), D[d] (formats RRRW, RCRW) or pos (formats RRPW, RCPW), and
extending for the number of bits specified by either E[d][36:32] (formats RRRR, RCRR) or width (formats RRRW,
RRPW, RCRW, RCPW). Put the bitwise OR of the two extracted words into D[c].
INSERTD[c], D[a], const4, pos, width (RCPW)
mask = (2
width
-1) << pos;
D[c] = (D[a] & ~mask) | ((zero_ext(const4) << pos) & mask);
If pos + width > 32, then the result is undefined.
INSERTD[c], D[a], const4, E[d] (RCRR)
width = E[d][36:32];
mask = (2
width
-1) << E[d][4:0];
D[c] = (D[a] & ~mask) | ((zero_ext(const4) << E[d][4:0]) & mask);
If E[d][4:0] + E[d][36:32] > 32, then the result is undefined.
INSERTD[c], D[a], const4, D[d], width (RCRW)
mask = (2
width
-1) << D[d][4:0];
D[c] = (D[a] & ~mask) | ((zero_ext(const4) << D[d][4:0]) & mask);
If D[d][4:0] + width > 32, then the result is undefined.
INSERTD[c], D[a], D[b], pos, width (RRPW)
mask = (2
width
-1) << pos;
D[c] = (D[a] & ~mask) | ((D[b] << pos) & mask);
If pos + width > 32, then the result is undefined.
31
c
28 27
pos
23 22
00
H
21 20
width
16 15
const4
12 11
a
8 7
B7
H
0
31
c
28 27
d
24 23
00
H
21 20
-
16 15
const4
12 11
a
8 7
97
H
0
31
c
28 27
d
24 23
00
H
21 20
width
16 15
const4
12 11
a
8 7
D7
H
0
31
c
28 27
pos
23 22
00
H
21 20
width
16 15
b
12 11
a
8 7
37
H
0
