Infineon TriCore TC1.6P User Manual

TriCore
®
TC1.6P & TC1.6E
32-bit Unified Processor Core
Instruction Set
V1.0 2013-07
User Manual (Volume 2) 3-138
JLTZ (16-bit)
Jump if Less Than Zero (16-bit)
Description
JLTZD[b], disp4 (SBR)
Status Flags
Examples
See Also
JGEZ (16-bit), JGTZ (16-bit), JLEZ (16-bit), JNZ (16-bit), JZ (16-bit)
If the contents of D[b] are less than zero then add the value specified by disp4, zero-extended and multiplied by
2, to the contents of PC and jump to that address.
if (D[b] < 0) then PC = PC + zero_ext(disp4) * 2;
C Not set by this instruction.
V Not set by this instruction.
SV Not set by this instruction.
AV Not set by this instruction.
SAV Not set by this instruction.
jltz d2, foobar
15
b
12 11
disp4
8 7
0E
H
0
