TriCore

TC1.6P & TC1.6E

32-bit Unified Processor Core

Instruction Set

V1.0 2013-07

User Manual (Volume 2) 3-345

Examples

shas d3, d1, d2

shas d3, d1, #26

See Also

SH, SH.H, SHA, SHA.H

AV advanced_overflow = result[31] ^ result[30];

if (advanced_overflow) then PSW.AV = 1 else PSW.AV = 0;

SAV if (advanced_overflow) then PSW.SAV = 1 else PSW.SAV = PSW.SAV;
