Infineon TriCore TC1.6P User Manual

TriCore
®
TC1.6P & TC1.6E
32-bit Unified Processor Core
Instruction Set
V1.0 2013-07
User Manual (Volume 2) 3-341
shift_count = 0 - D[b][5:0];
msk = D[a][31] ? (((1 << shift_count) - 1) << (32 - shift_count)) : 0;
result = msk | (D[a] >> shift_count);
carry_out = (D[a][shift_count - 1:0] != 0);
}
D[c] = result[31:0];
SHAD[a], const4 (SRC)
Status Flags
Examples
sha d3, d1, d2
sha d3, d1, #26
See Also
SH, SH.H, SHAS, SHA.H
if (const4[0:3] >= 0) then {
carry_out = const4[0:3] ? (D[a][31:32 - const4[0:3]] != 0) : 0;
result = D[a] << const4[0:3];
} else {
shift_count = 0 - const4[0:3];
msk = D[a][31] ? (((1 << shift_count) - 1) << (32 - shift_count)) : 0;
result = msk | (D[a] >> shift_count);
carry_out = (D[a][shift_count - 1:0] != 0);
}
D[a] = result[31:0];
C if (carry_out) then PSW.C = 1 else PSW.C = 0;
V overflow = (result > 7FFFFFFF
H
) OR (result < -80000000
H
);
if (overflow) then PSW.V = 1 else PSW.V = 0;
SV if (overflow) then PSW.SV = 1 else PSW.SV = PSW.SV;
AV advanced_overflow = D[c][31] ^ D[c][30];
if (advanced_overflow) then PSW.AV = 1 else PSW.AV = 0;
SAV if (advanced_overflow) then PSW.SAV = 1 else PSW.SAV = PSW.SAV;
sha d1, #6
15
const4
12 11
a
8 7
86
H
0
