Infineon TriCore TC1.6P User Manual

TriCore
®
TC1.6P & TC1.6E
32-bit Unified Processor Core
Instruction Set
V1.0 2013-07
User Manual (Volume 2) 3-44
Status Flags
Examples
bisr #126
See Also
DISABLE, ENABLE, LDLCX, LDUCX, STLCX, STUCX, SVLCX, RET, RFE, RSLCX, RSTV
if (FCX == 0) trap(FCU);
EA = {FCX.FCXS, 6'b0, FCX.FCXO, 6'b0};
new_FCX = M(EA, word);
M(EA,16 * word) = {PCXI, A[11], A[2], A[3], D[0], D[1], D[2], D[3], A[4], A[5], A[6], A[7], D[4], D[5], D[6], D[7]};
PCXI.PCPN = ICR.CCPN;
PCXI.PIE = ICR.IE;
PCXI.UL = 0;
PCXI[19:0] = FCX[19:0];
FCX[19:0] = new_FCX[19:0];
ICR.IE = 1;
ICR.CCPN = const8;
if (tmp_FCX == LCX) trap(FCD);
C Not set by this instruction.
V Not set by this instruction.
SV Not set by this instruction.
AV Not set by this instruction.
SAV Not set by this instruction.
bisr #126
