iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
144
Table 4.4.5.1-1 SYSTEM ATTRIBUTES
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
SMDR/ACD/Alarm Mail Attribute
Common SMTP Attributes
SMTP Server IP
Address
SMTP server IPv4 address to receive the SMDR E-mail reports.
12-digits
0.0.0.0
SMTP Server
Domain Address
SMTP Mail server Domain address to receive the SMDR e-mail
reports. Check DNS IP address setting.
SMTP Port
This field defines the TCP/IP port the system will employ when
communicating with the SMTP E-mail server. (It is moved to web
admin PGM 160-161)
1-65535
25
SMTP Security
Connection
The system can support basic security policies when
communicating with the SMTP E-mail server. Note the server
must also be configured for the selected security protocol.
No security, SSL, TLS
Refer to
description
No security
E-Mail Account
ID
This field defines the user’s ID for the SMTP server. If the user’s
ID and password are assigned, the SMTP server will check the
validity of the user ID and password.
Max.64char
acters
E-Mail Account
Password
This field defines the user‘s password for the SMTP server. If
the user‘s ID and password are assigned, the SMTP Mail server
will check the validity of the user ID and password.
Max.64
characters
Sender E-Mail
Address (From)
E-Mail addresses as the “From” address when sending
Database, SMDR, ACD, and Alarm reports.
Max.64char
acters
Sender System
Domain Name
The domain name of the SMTP Mail server to receive SMDR
reports. This field is used in place of the SMTP Mail Server IP
Address above.
Max. 18
characters
Database Attributes [Send Mail]
[Send Mail] button is used for sending the mail after filling out the below menu
Database Mail
Send Monthly
Set
Sets day of the month for Database to be sent on a monthly
basis (NA for no monthly reports, select the day for 1 or 15).
NA/
1/
15
NA
Database Mail
Send Weekly Set
Sets day of the week to send Database weekly.
Day-of
week
N/A
Database Type
Select the desired database type: All database, System speed,
Station speed, LCR, etc.
All
Database
Database
Receiver Mail
Address
E-mail address to receive the Database E-mail reports.
Max. 64
characters
SMDR Attributes
[Send Mail] button is used for sending the mail after filling out the below menu
SMDR Mail Send
Weekly Set
Sets day of the week to send SMDR data weekly.
NA,
Monday to
Sunday
N/A
