iPECS UCP600 - Page 160

iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
146
Table 4.4.5.1-1 SYSTEM ATTRIBUTES
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
Search Base
Server base means Search option. You can get the search
option from the LDAP Server manager. For example, if OU
(Organization Unit) is OC and DC (Directory Company) is ucapp
and com, you can give the option "OU=OC, DC=ucapp,
DC=com" in this field. You will get the desired directory.
Max. 100
characters
LDAP User ID
ID and Password must be required to connect to LDAP Server.
LDAP User
Password
All
characters
Resource Monitoring
Resource monitoring is a software function to log the over usage events of some CPU resources. This
function is implemented to find out the root cause of unwanted system reboot by high CPU load. The log data
by resource monitoring is a built-in system DB file and checked by using maintenance CLI ‘smblog view’.
Resource
Monitoring
Process
This option determines whether to turn on/off a function.
OFF
ON
OFF
Event Log
Interval Time
This value specifies an interval time of the event log when the
same event is detected consecutively. The purpose is to avoid
CPU overhead from logging events frequently. A minimum value
that can be programmed is 10 seconds.
10-3600sec
60
Reboot on
Detecting
because of File
Open Overflow
By software bug, file open leak problem can happen, and the
user can't connect to the web page or system can't work
correctly if this type of leak happens, System will be rebooted if
this field is configured to ON after log event.
OFF
ON
OFF
Reboot on
Detecting
because of
Memory Usage
Overflow
The system will reboot by itself when memory over usage
happens. Up to now, this function is not implemented.
OFF
ON
OFF
Free Memory
Threshold
This value specifies a threshold value to detect memory leakage
events.
KB, 1-
65535
4096
Reboot on
Detecting
because of CPU
Usage Overflow
The system will reboot by itself when CPU over usage happens.
Up to now, this function is not implemented.
OFF
ON
OFF
CPU Usage
Threshold
This value specifies the threshold value to detect CPU over
usage events.
95
Reboot on
Detecting
because of
Network Busy
Traffic
The system will reboot by itself when a busy network usage
(receiving side) happens. Up to now, this function is not
implemented.
OFF
