iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
258
Table 4.4.8.3-1 SIP CO ATTRIBUTES
Privacy(CLIR)
Presentation
SIP employs various headers that include a User Id and Name. In
some cases, it may be desirable to restrict the called party from
receiving this information. Several options for Caller Id restriction
can be applied.
Anonymous Name & Anonymous Number,
Anonymous Name,
Privacy: user, Privacy: id,
Privacy: user; id; critical,
Privacy: id & anonymous & P-Preferred-ID
Anonymous
Name &
Anonymous
Number
The Id in the “From” header of SIP messages can be based on
the calling station, the User Id, or a fixed User Id.
Extension SIP User Id: one of three SIP User Ids is
assigned to the station in PGM 111. Select which of the three
indices to use in the SIP UID Selection below.
Extension outgoing CLI: the CLI configured for the station
through Web PGM 113 and 151.
Authorized Representative Id: the User Id of the
“Authorized Representative Id” assigned to the SIP User Id
that is indexed to the station in PGM 111. The specific index
is selected below as the SIP UID Selection.
Fixed Table: the SIP User ID from the SIP UID Fixed Table
Index attribute is assigned below.
Extension
SIP-
User-ID
Table
The “Display” field of the “From” header can be configured to use
the below:
System Rule:
- a. From ID = Extension SIP User-ID Table, display
Contact Display Name from PGM 126, otherwise display
Station Name from PGM 111 or blank.
- b. From ID = Extension Outgoing CLI, display Station
Name from PGM 111 or blank.
- c. From ID = Authorized Rep Id, display Contact Display
Name of Authorized Rep Id from PGM 126; otherwise,
display Station Name from PGM 111 or blank.
- d. From ID = Fixed Table display Contact Display Name
from PGM 126 or Station Name from PGM 111 or blank.
Extension outgoing CLI: the CLI configured for the station
through Web PGM 113 and 151
